*Full HD AF ZOOM Camera Module
*全面兼容索尼FCB-EH6300硬件接口和协议
*20倍光学,210万像素1080P输出
*1/2.9 " CMOS 16倍电子放大
Specifications
|
Models
|
HSM-H71D*Z2
|
|
|
|
Lens
|
Optical Zoom 20x(f=4.7mm ~ 94.0mm) F1.6(wide)~ F3.5(tele)
|
|
Image Sensor
|
1/2.9” CMOS 2.1M
|
|
Scanning Mode
|
Progressive Scan
|
|
Zoom Movement Speed
|
Optical WIDE to Optical TELE: 2.0 sec (Variable)
Digital WIDE to Digital TELE: 4.0 sec
|
|
Digital Zoom
|
16x (320x with optical zoom)
|
|
Min. Working Distance
|
30 mm (WIDE end), 1000 mm (TELE end)
|
|
Focusing System
|
AUTO, ONE PUSH AF, MANUAL
|
|
Effective Pixels (H x V)
|
1920 x 1080
|
|
Image Size (H x V)
|
1920 x 1080, 1280 x 720
|
|
Recommended Illumination
|
100 lx ~ 100,000 lx
|
|
Back Light Compensation
|
Yes (ON/OFF)
|
|
Electronic Shutter Speed
|
1/30 sec ~ 1/60,000 sec (12 steps)
|
|
White Balance
|
AUTO, AUTOext(Sodium Vapor Lamp), PRESET(One Push), Manual
|
|
AE Control
|
AUTO, IRIS Manual, SHUTTER Manual
|
|
Wide Dynamic Range
|
Yes (ON/OFF, Max 15 fps)
|
|
True Day and Night (IR-cut filter)
|
Yes
|
|
Noise Reduction (2D, 3D)
|
Yes (ON/OFF)
|
|
Slow Shutter
|
Yes
|
|
Color Enhancement
|
Yes
|
|
Aperture Control
|
Yes
|
|
Lens Shading
|
Yes
|
|
Defect Suppression
|
Yes
|
|
VIDEO
|
|
Resolution
|
1080p@30fps, 720p@60fps
|
|
Composite Out
|
NTSC/PAL Selectable
|
|
IN/OUT
|
|
Video Out
|
HD: Digital(LVDS), SD: Analog(CVBS)
|
|
RS232C
|
Yes
|
|
CHARACTERISTICS
|
|
Operating Temperature
|
-5℃~ +60℃
|
|
Power Supply
|
DC12V
|
|
Power Consumption
|
Under 3.0W
|
|
FEATURES
|
|
Camera Title / ID Display
|
Yes
|
|
Privacy Zone Masking
|
Max 24
|
|
Video Preset
|
Yes
|
|
Video Motion Detection
|
Specific Area/Full Screen
|
|
Digital PTZ
|
x16
|
|
Video Flip / Mirror / Freeze
|
Yes
|
|
Camera Control Interface
|
CMOS 5V Level 2.4~38.4 Kbps HITRON/VISCA
|
※ Specifications are subject to change without notice.
